System Specifications

Speed Rating (per unit)
AC2100

Number of Bands
Tri-band

Coverage
6000 sq. ft. /557 m2

Wireless Standard
IEEE 802.11 b/g/n 2.4 GHz
IEEE 802.11 a/n/ac Wave 2, 5 GHz

Wireless Transfer Rate
Transmit & Receive:
866 Mbps for 5 GHz (dedicated backhaul)
866 Mbps for 5 GHz
300 Mbps for 2.4 GHz

WiFi Features
Bridge Mode
MU-MIMO
Auto path selection
Single WiFi Name
AP Steering
Band Steering
Optional to separate 2.4G and 5G WiFi network

App

Ease of use
Mobile App Support iOS 9 or later and Android 5.0 or later
Registration setup via social media or myZyxelCloud login
Quick Bluetooth setup
Find the best installation locations with graphical indication
Remote control Multy WiFi system
Multy WiFi system online/offline status check
Automatic firmware check for new features
Diagnose network health via speed test
WiFi signal diagnose between mobile device to Multy

Internet access control
Device grouping: Organize multiple devices into group
Block or allow specific group based on time schedule
Flexible override Internet access for specific device group
Support selection of 15-minute intervals in schedule settings

Guest WiFi setting

Push notification
New device connected
New firmware available
Speed test result

Speed test
Mobile device to Internet

Support language
EN/DE/FR/CN/ES/IT/PT

Software, Security

Software & Security
Firewall security (NAT)
IPv6 compatible
DMZ
Port Forwarding
UPnP
WPA2-Personal encryption
QoS
Network monitoring & diagnosis
Auto firmware update
Parental control

Hardware Specifications

CPU
1 GHz Dual-Core

Memory
256 MB RAM

Flash
512 MB

WAN
One 10/100/1000 Mbps Ethernet RJ-45 port with auto MDI/MDIX support

LAN
One 10/100/1000 Mbps Ethernet RJ-45 ports with auto MDI/MDIX support

Antenna
6 internal antennas

Bluetooth
BLE 4.1

LED indicator
Status indication/auto dimming

Button
LED On/Off
Reset

Power
12 V DC, 1.5 A

Power consumption
14 watt

Physical Specifications

Item
Item dimensions (WxDxH): 123 x 123 x 30 mm (4.8 x 4.8 x 1.2)
Item weight: 310 g (0.68 lb. )

Pack of 2
Packing dimensions (WxDxH): 316 x 158 x 95 mm (12.44 x 6.22 x 3.74)
Packing weight: 1430 g (3.15 lb. )

Environmental Specifications

Operating Environment
Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10% to 90% (Non-condensing)

Storage Environment
Temperature: -30°C to 70°C (-22°F to 158°F)
Humidity: 10% to 95% (Non-condensing)

Certifications

Safety
CE-LVD, BSMI

EMC
EMC: CE, FCC, BSMI, NCC

Package Contents
Multy U
Power adapter
Ethernet cable
Leather strap
Quick start guide
